輸入壓力：≤0.6Mpa輸出壓力：≤0.4Mpa

輸出流量:0-100ml/min;0-200ml/min; 0-300ml/min;0-1000ml/min;0-2000ml/min  0-1000ml/min (≥ 0.25 Mpa)
輸入輸出壓降: ≥0.05Mpa

穩流精度: ≤2.0％ FL/15min
安裝開孔:Ф12.5mm

輸入輸出管徑: Ф2.0mm
外形尺寸：38×103

用途：廣泛用于氣體流量穩定的自動調節，諸如色儀,原子吸收，火焰光度，生化儀器，石油化工及環保儀器等。特殊需要另行安排定制。

使用說明:氣體穩流閥通常為1個進口2個出口,其中一個出口可接壓力表或不用堵住.進口處標有箭頭. 輸出流量的大小通過旋鈕調節,逆時針轉動輸出流量增大,反之, 順時針轉動輸出流量減小.精密閥門應緩慢調節.為了達到良好的穩流效果,一般要在穩流閥前加接穩壓閥.

Precision gas flow valve
Precision gas steady flow valve Details:

WLF-1 precision gas flow valve

Input pressure: ≤0.6Mpa Output pressure: ≤0.4Mpa
Output flow: 0-100ml/min; 0-200ml/min; 0-300ml/min; 0-1000ml/min; 0-2000ml/min 0-1000ml/min (≥ 0.25 Mpa)
Input and output pressure drop: ≥0.05Mpa
Steady flow accuracy: ≤2.0% FL/15min
Installation hole: Ф12.5mm
Input and output pipe diameter: Ф2.0mm
Dimensions: 38×103

Uses: Widely used for automatic adjustment of gas flow stability, such as colorimeter, atomic absorption, flame photometry, biochemical instruments, petrochemical and environmental protection instruments, etc. Special needs can be customized separately.

Instructions for use: The gas steady flow valve usually has 1 inlet and 2 outlets. One of the outlets can be connected to a pressure gauge or does not need to be blocked. The inlet is marked with an arrow. The output flow is adjusted by the knob, and the output flow is increased by turning counterclockwise. On the contrary, turn clockwise to reduce the output flow. The precision valve should be adjusted slowly. In order to achieve a good flow stabilization effect, it is generally necessary to add a regulator valve before the flow stabilization valve.
